Two short passages off a wide two-bedroom living room

Shared by Lodnor plan previews

Published

Comments
Two short passages off a wide two-bedroom living room conceptual 3D model

Loading the 3D view. The published poster remains visible.

Conceptual model only. Not a survey or construction document.

Measurements

All measurements are approximate.

Overall width
≈ 8.0 m
Overall depth
≈ 6.6 m
Model height
≈ 3.0 m
Spaces
8

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

The bedrooms sit above the living area, with two bathroom bays between them. Separate short passages serve this upper room group, while a kitchen occupies the opposite end of the living room behind a doorway. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 3265 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ .

Finishes

  • Wall stucco ivory

About this model

This 3D model was reconstructed by INK TO BRICK from a floor plan the creator uploaded. It is a conceptual model for exploring rooms, furniture and finishes, not a survey or construction document.
