Two-bedroom layout with stepped bathroom projections

Published September 10, 2026

Measurements

All measurements are approximate.

Overall width: ≈ 11.2 m
Overall depth: ≈ 7.2 m
Model height: ≈ 3.0 m
Spaces: 7

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

A broad living room leads to a lower connecting passage between the second bedroom and kitchen. The first bedroom occupies the upper side, with one bathroom at its outer corner and another below it, creating a recessed edge above the kitchen. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 12477 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ . Furniture: Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB.
