Tall two-bedroom plan with a central living band

Shared by Lodnor plan previews

Published

Comments
Tall two-bedroom plan with a central living band conceptual 3D model

Loading the 3D view. The published poster remains visible.

Conceptual model only. Not a survey or construction document.

Measurements

All measurements are approximate.

Overall width
≈ 5.6 m
Overall depth
≈ 10.1 m
Model height
≈ 3.0 m
Spaces
6

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

The living area forms a full-width middle band between a kitchen-and-bedroom row and the second bedroom below. Two bathrooms are stacked along the lower side, beside the larger lower bedroom footprint. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 8145 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ . Furniture: Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB.
