Two-bedroom plan with a wide living room and side recess

Shared by Lodnor plan previews

Published

Comments
Two-bedroom plan with a wide living room and side recess conceptual 3D model

Loading the 3D view. The published poster remains visible.

Conceptual model only. Not a survey or construction document.

Measurements

All measurements are approximate.

Overall width
≈ 9.4 m
Overall depth
≈ 8.5 m
Model height
≈ 3.0 m
Spaces
6

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

A broad living room extends into a central connecting area between the two bedrooms. Two bathrooms and the enclosed kitchen line the lower edge, while a recess separates the kitchen from the upper bedroom along the side. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 11277 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ . Furniture: Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB.

Finishes

  • Wall timber charcoal

About this model

This 3D model was reconstructed by INK TO BRICK from a floor plan the creator uploaded. It is a conceptual model for exploring rooms, furniture and finishes, not a survey or construction document.
