Two bedrooms and a kitchen around a notched living core

Shared by Lodnor plan previews

Published

Comments
Two bedrooms and a kitchen around a notched living core conceptual 3D model

Loading the 3D view. The published poster remains visible.

Conceptual model only. Not a survey or construction document.

Measurements

All measurements are approximate.

Overall width
≈ 10.2 m
Overall depth
≈ 9.7 m
Model height
≈ 3.0 m
Spaces
6

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

The living area turns between a kitchen and two bedrooms at opposite corners, reaching a recessed outer edge between the upper rooms. Horizontal bathroom bays sit below the kitchen and upper bedroom, with a second recess along the side. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 8063 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ . Furniture: Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB.
