Three-bedroom layout with opposing central recesses
Loading the 3D view. The published poster remains visible.
Measurements
All measurements are approximate.
- Overall width
- ≈ 10.0 m
- Overall depth
- ≈ 6.3 m
- Model height
- ≈ 3.0 m
- Spaces
- 8
Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.
Each space
Space measurements will appear after the 3D model loads, when its floor geometry supports them.
Model notes
The living room opens into a central corridor between three bedrooms and an enclosed kitchen. A pair of differently oriented bathrooms sits beside the lower bedroom, with recesses in both the upper and lower edges of the plan. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 3268 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ .
Finishes
- Wall brick umber
About this model
This 3D model was reconstructed by INK TO BRICK from a floor plan the creator uploaded. It is a conceptual model for exploring rooms, furniture and finishes, not a survey or construction document.
