Three-bedroom plan with a projecting kitchen and living alcove

Shared by Lodnor plan previews

Published

Comments
Three-bedroom plan with a projecting kitchen and living alcove conceptual 3D model

Loading the 3D view. The published poster remains visible.

Conceptual model only. Not a survey or construction document.

Measurements

All measurements are approximate.

Overall width
≈ 11.3 m
Overall depth
≈ 7.2 m
Model height
≈ 3.0 m
Spaces
7

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

The living area opens into an upper alcove beside the kitchen, which projects from the outer edge. Two bedrooms share one side and the third occupies the lower opposite corner, with two bathrooms grouped beside the upper bedroom. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 16504 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ .
