Three-bedroom plan with an open cross-plan passage

Published September 10, 2026

Measurements

All measurements are approximate.

Overall width: ≈ 13.1 m
Overall depth: ≈ 8.0 m
Model height: ≈ 3.0 m
Spaces: 8

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

An open passage links the kitchen and living area, with paired bathrooms beside the upper bedroom and two more bedrooms along the lower edge. The modeled entrance does not yet match the source. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 13115 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ . Furniture: Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB.
