E. Fay and Gus Jones House

Published September 10, 2026

Measurements

All measurements are approximate.

Overall width: ≈ 17.4 m
Overall depth: ≈ 9.3 m
Model height: ≈ 6.2 m
Spaces: 20

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

2 floors reconstructed from HABS drawings. Historic American Buildings Survey, AR-52. HABS public-domain measured drawings: https://commons.wikimedia.org/wiki/File:First%20Floor%20Plan%20-%20E.%20Fay%20and%20Gus%20Jones%20House%2C%201330%20North%20Hillcrest%20Avenue%2C%20Fayetteville%2C%20Washington%20County%2C%20AR%20HABS%20AR-52%20(sheet%203%20of%2023).png Production reconstruction, not a survey or construction document. Floor heights estimated; floors aligned automatically; horizontal scale unverified. Stairs and inter-floor routes unconfirmed, including where no stairs are modeled. Decorative finish palette is not evidence of original construction. 3 assembly blockers remain. 0 stair proposals; none confirmed.

Finishes

Wall timber charcoal

About this model

This 3D model was reconstructed by INK TO BRICK from a floor plan the creator uploaded. It is a conceptual model for exploring rooms, furniture and finishes, not a survey or construction document.
