Three-bedroom plan with side bathrooms and an open entry room

Published September 10, 2026

Measurements

All measurements are approximate.

Overall width: ≈ 10.9 m
Overall depth: ≈ 9.9 m
Model height: ≈ 3.0 m
Spaces: 9

Overall dimensions are maximum model spans. Model height is not a ceiling height. Modeled floor area is not a verified living-area measurement.

Each space

Space measurements will appear after the 3D model loads, when its floor geometry supports them.

Model notes

Two stacked bathroom bays separate the bedrooms along one side of the plan, while the third bedroom sits beside an unlabeled entry-side room. The living area connects that room and the bedroom corridor, with an enclosed kitchen projecting from the opposite side. Approximate reconstruction. Furniture and finishes are illustrative, not measured fit or evidence of existing conditions. Source: The ResPlan Authors, ResPlan plan 2013 (CC BY 4.0): https://github.com/m-agour/ResPlan . License: https://creativecommons.org/licenses/by/4.0/ . Furniture: Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB.

Finishes

Wall brick terracotta

About this model

This 3D model was reconstructed by INK TO BRICK from a floor plan the creator uploaded. It is a conceptual model for exploring rooms, furniture and finishes, not a survey or construction document.
