Casa Bajamar: Tall two-bedroom plan with a lower-set kitchen bay
Tall two-bedroom plan with a lower-set kitchen bay. A layout study from ResPlan 12146.
Casa Bajamar is the editorial name for this two-bedroom layout study based on ResPlan 12146. The public tour offers a way to inspect room connections and boundaries; the name does not identify a built residence or commissioned renovation.
Reading the Casa Bajamar layout
Two bedrooms form one side, with the upper room extending alongside a pair of narrow bathrooms. The kitchen sits lower along the opposite outer edge, above the living room and beside the short connecting passage.
The public model reports an approximate overall envelope of 8.714 × 8.819 m, with a modeled height of 3 m. These figures describe the reconstruction, not usable floor area, individual room dimensions or a verified building survey.
Loading the published model…
How the room routes connect
The kitchen in Casa Bajamar begins lower than the upper bedroom-and-bathroom group. This offset changes where movement enters the shared living side. Locate the short connecting passage and follow it toward both bedrooms before deciding which living-room edge can hold furniture. The pair of narrow bathrooms needs its own doorway reading rather than a guessed route across the kitchen.
A furniture decision to compare
The offset kitchen creates a useful comparison between a dining position beside its opening and one farther into the lower living room. Keep the upper room row as a separate reference, so the plan is not described as two matching strips. The upper bedroom extension is a footprint fact; it does not demonstrate extra windows, greater daylight or a specific furnishing capacity.
Review exercise: Casa Bajamar
In plan view, mark the kitchen’s upper edge and the upper bedroom’s projection. Trace kitchen-to-each-bedroom journeys through the short connection. Compare the two dining positions with a chair in use, then inspect the bathroom approaches. Save a note identifying the offset that each option respects or crowds; do not substitute the overall width for a local clearance measurement.
Source and scope of this study
Source: The ResPlan Authors, ResPlan plan 12146. Original ResPlan collection, licensed under Creative Commons Attribution 4.0. Lodnor reconstructed the plan in 3D. The editorial project name and furniture proposals in this article do not attribute new design intentions to the source authors.
The public release credits furniture by Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB. Furniture sizes and finishes are illustrative; check real dimensions before purchasing.
