Casa Articulación: Three-bedroom plan with a central unlabeled connecting room
Three-bedroom plan with a central unlabeled connecting room. A layout study from ResPlan 6016.
Casa Articulación is the editorial name for this three-bedroom layout study based on ResPlan 6016. The public tour offers a way to inspect room connections and boundaries; the name does not identify a built residence or commissioned renovation.
Reading the Casa Articulación layout
An unlabeled central room links the kitchen, living area, and bedroom corridor beneath a shallow exterior recess. Two bedrooms share one side and a third sits along the lower edge, with separate bathroom bays beside the corridor.
The public model reports an approximate overall envelope of 11.606 × 8.174 m, with a modeled height of 3 m. These figures describe the reconstruction, not usable floor area, individual room dimensions or a verified building survey.
Loading the published model…
How the room routes connect
Casa Articulación makes an unlabeled central room the link between kitchen, living area and bedroom corridor. Its connecting role is clear in the summary even though its intended activity is not. Trace all three directions before choosing a room name or furniture use. The shallow recess above it remains exterior geometry, not extra indoor area for a proposed dining arrangement.
A furniture decision to compare
The safest design discussion starts with a flexible connector rather than a fixed new function. Compare leaving the middle mostly open with a small movable piece held at its edge. Keep the bedroom corridor distinct from that room and check both separated bathroom bays. Calling the center a dining room would be a proposal that still needs its circulation tested.
Review exercise: Casa Articulación
Mark kitchen, living and bedroom-corridor directions around the unlabeled center. Trace a triangle of trips between them, then add the lower bedroom and bathroom approaches. Imagine a compact movable table against one edge and repeat the trips. Record whether its use can coexist with the connector role; retain the source’s missing label in your notes.
Source and scope of this study
Source: The ResPlan Authors, ResPlan plan 6016. Original ResPlan collection, licensed under Creative Commons Attribution 4.0. Lodnor reconstructed the plan in 3D. The editorial project name and furniture proposals in this article do not attribute new design intentions to the source authors.
The public release credits furniture by Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB. Furniture sizes and finishes are illustrative; check real dimensions before purchasing.
