Casa Banda Media: Three-bedroom plan with a broad middle living band
Three-bedroom plan with a broad middle living band. A layout study from ResPlan 9213.
Casa Banda Media is the editorial name for this three-bedroom layout study based on ResPlan 9213. The public tour offers a way to inspect room connections and boundaries; the name does not identify a built residence or commissioned renovation.
Reading the Casa Banda Media layout
The living area spans the middle between an upper bedroom, paired bathrooms, and the kitchen, with two more bedrooms below. The kitchen and lower corner bedroom project past the narrower side of the living area.
The public model reports an approximate overall envelope of 7.882 × 9.73 m, with a modeled height of 3 m. These figures describe the reconstruction, not usable floor area, individual room dimensions or a verified building survey.
Loading the published model…
How the room routes connect
The middle living band in Casa Banda Media connects an upper room row with two lower bedrooms. The projecting kitchen and lower corner bedroom change its side edge, so movement cannot be inferred from one neat rectangular band. Follow each trip through the actual shared floor and identify where it turns toward the projections. The paired upper bathrooms add their own approaches.
A furniture decision to compare
Furnishing across the central band may interrupt several north-to-south trips in the drawing, so compare an arrangement along one edge first. This is a geometric reading, not a cardinal orientation for a real site. Keep both side projections visible when testing the proposal. Their differing local widths should be reviewed individually rather than using the plan’s widest overall dimension for every clearance.
Review exercise: Casa Banda Media
Trace kitchen-to-each-bedroom trips through the middle band and mark their crossing points. Compare furniture aligned along the band with furniture set across it. Include the upper bathroom approaches in both sketches. Inspect the projecting lower bedroom’s turn separately, and note which constraint belongs to the shared band versus the narrower side relationship.
Source and scope of this study
Source: The ResPlan Authors, ResPlan plan 9213. Original ResPlan collection, licensed under Creative Commons Attribution 4.0. Lodnor reconstructed the plan in 3D. The editorial project name and furniture proposals in this article do not attribute new design intentions to the source authors.
The public release credits furniture by Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB. Furniture sizes and finishes are illustrative; check real dimensions before purchasing.
