Casa Lucerna: Two-bedroom layout with stepped bathroom projections
Two-bedroom layout with stepped bathroom projections. A layout study from ResPlan 12477.
Casa Lucerna is the editorial name for this two-bedroom layout study based on ResPlan 12477. The public tour offers a way to inspect room connections and boundaries; the name does not identify a built residence or commissioned renovation.
Reading the Casa Lucerna layout
A broad living room leads to a lower connecting passage between the second bedroom and kitchen. The first bedroom occupies the upper side, with one bathroom at its outer corner and another below it, creating a recessed edge above the kitchen.
The public model reports an approximate overall envelope of 11.163 × 7.189 m, with a modeled height of 3 m. These figures describe the reconstruction, not usable floor area, individual room dimensions or a verified building survey.
Loading the published model…
How the room routes connect
The lower connecting passage gives Casa Lucerna a route that can disappear in a decorative overview. Locate it before deciding where the living room ends. Movement toward the second bedroom and the kitchen shares this lower connection, while the upper bedroom belongs to a different edge. Furnishing the whole visible center as seating would blur that distinction.
A furniture decision to compare
The stepped bathroom projections make the exterior outline more informative than a bounding rectangle. They help explain why the kitchen edge is recessed and why neighboring rooms have different available wall lengths. Use those lengths separately when considering storage. A cabinet run borrowed from the broader living room may not transfer to the narrower connecting zone.
Review exercise: Casa Lucerna
Compare two camera views: one above the lower passage and one facing the stepped bathroom edge. Trace the living-to-kitchen route in the first, then identify which walls actually enclose it in the second. Sketch a storage idea only after marking the required turning space. Record any doorway whose connection you cannot establish from the published model.
Source and scope of this study
Source: The ResPlan Authors, ResPlan plan 12477. Original ResPlan collection, licensed under Creative Commons Attribution 4.0. Lodnor reconstructed the plan in 3D. The editorial project name and furniture proposals in this article do not attribute new design intentions to the source authors.
The public release credits furniture by Eric Chadwick, ©2021 Wayfair, LLC, CC BY 4.0, modified for presentation. Full furniture and material credits are embedded in the GLB. Furniture sizes and finishes are illustrative; check real dimensions before purchasing.
